LN6025 - 80
SINGLE PHASE SSR
Output Load Specification
Operating Voltage: 240 Volts rms
Load current @ 25°C: 15 to 75 Amps (rms)
Operating temperature: -20 to +85 °C
Transient overvoltage: 600 Volts rms
Isolation, (input – output): 2,500 Volts rms
Control Input Specification
Control Voltage,
VF
: 3.5 to 32 Volts dc
Control current, (Max)
IF : 25 mAmps
Reverse voltage, (Max) : 3 Volts dc
